Caledonia Yawl II
Description
The Caledonia Yawl 7 Strake Version, also known as the Caledonia Yawl II, is an enhanced iteration of Iain Oughtred's original Caledonia Yawl design, introduced in 1999. This version features a refined hull with seven planks per side (compared to the original's four), offering improved stability, increased displacement, and a slightly different aesthetic while retaining the boat's renowned seaworthiness, versatility, and traditional double-ended charm. Like its predecessor, it is primarily built by amateur constructors using glued-lapstrake plywood and is popular for coastal cruising, rowing, and multi-day "raid" events.
Construction Details
| Designer | Iain Oughtred |
|---|---|
| Builder | Home Built |
| Length | 19.500 ft |
| LOA | 19.500 ft |
| LWL | 16.083 ft |
| Beam | 6.417 ft |
| Displacement | 650 lb |
| Max Draft | 3.831 ft |
| Min Draft | 0.750 ft |
| Year Built | 1999 |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | - |
| e | - |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| - | - | - | - | - | - | - | - |
Blueprints
Sails
Caledonia Yawl II - JIBSAIL
| Luff | 14.33 ft - (4368 mm) |
|---|---|
| Foot | 6.33 ft - (1929 mm) |
| Leech | 12.5 ft - (3810 mm) |
| Area | * 39.5 ft² |
| Edit in Calculator |
Caledonia Yawl II - BALANCE LUGSAIL
| Luff | 9.75 ft - (2972 mm) |
|---|---|
| Foot | 10.75 ft - (3277 mm) |
| Leech | 19.25 ft - (5867 mm) |
| Tack Angle | 12.33 ° |
| Diag (clew/throat) | 13 ft - (3962 mm) |
| Head | 78.5 ft - (23927 mm) |
| Area | 130.55 ft² |
| Edit in Calculator |
Caledonia Yawl II - GUNTER
| Luff | 9.83 ft - (2996 mm) |
|---|---|
| Foot | 9.83 ft - (2996 mm) |
| Leech | 20.167 ft - (6147 mm) |
| Tack Angle | * 78.96 ° |
| Diag (clew/throat) | 12.5 ft - (3810 mm) |
| Head | 10.67 ft - (3252 mm) |
| Area | * 96.92 ft² |
| Edit in Calculator |
Caledonia Yawl II - LEG-O-MUTTON
| Luff | 10.33 ft - (3149 mm) |
|---|---|
| Foot | 5.33 ft - (1625 mm) |
| Leech | * 9.9 ft - (3018 mm) |
| Tack Angle | * 71.4 ° |
| Diag (clew/head) | 10 ft - (3048 mm) |
| Head (Inches) | 2 |
| Area | * 26.75 ft² |
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
