Catspaw Dinghy
Description
The Catspaw dinghy was designed by Joel White and N.G. Herrshoff. The boat performs well whether rowing, sailing and also tracks well while towing. The simple spritsail rig works very well with the boat in all conditions.
Construction Details
| Designer | Joel White |
|---|---|
| Length | 12.000 ft |
| LOA | 12.698 ft |
| Beam | 4.469 ft |
| Displacement | 175 lb |
| Max Draft | 1.670 ft |
| Min Draft | 0.540 ft |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | - |
| e | - |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| - | - | - | - | - | - | - | - |
Documents
Sails
Catspaw Dinghy - 4-SIDED SAIL
| Luff | 8.17 ft - (2490 mm) |
|---|---|
| Foot | 8.17 ft - (2490 mm) |
| Leech | 11.25 ft - (3429 mm) |
| Head | 5.67 ft - (1728 mm) |
| Diagonal | 10.67 ft - (3252 mm) |
| Tack Angle | 81.5 ° |
| Area | 62.87 ft² |
| Comments | Spritsail |
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
