Soverel 27
Description
The Soverel 27 is a 26.52-foot fractional sloop designed by Mark Soverel as a lightweight MORC (Midget Ocean Racing Club) rule racer. It was built in fiberglass by Tartan Marine (under the Soverel product line) between 1986 and 1987. Production was very limited — roughly 27 boats were completed before Tartan discontinued the entire Soverel line. The boat features a beamy, light-displacement hull optimized for performance, with a fin keel, spade rudder, and running backstays on some setups, making it quick and responsive in club PHRF racing or daysailing while offering basic accommodations for short cruises. Key features include solid early fiberglass construction, a large cockpit, and lively sailing characteristics suited to light-air and reaching conditions. It is a relatively rare model today, with occasional examples on the used market often set up for racing with upgraded rigging and sail inventories.
Construction Details
| Designer | Mark Soverel |
|---|---|
| Builder | Tartan Marine (USA) |
| Length | 26.520 ft |
| LOA | 26.520 ft |
| LWL | 21.920 ft |
| Beam | 8.750 ft |
| Displacement | 3900 lb |
| Ballast | 1600 lb |
| Max Draft | 5.000 ft |
| Year Built | 1986 |
The standard boat dimensions
| i | 35 ft |
|---|---|
| j | 10 ft |
| p | 33.30 ft |
| e | 11.28 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 35 ft | 10 ft | 33.30 ft | 11.28 ft | - | - | - | - |
Documents
Sails
Soverel 27 - MAINSAIL
| Luff | * 33.3 ft - (10150 mm) |
|---|---|
| Foot | * 11.28 ft - (3438 mm) |
| Leech | * 34.54 ft - (10528 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 34.78 ft - (10601 mm) |
| Head (inches) | * 5.25 in - (133 mm) |
| Area | * 194.04 ft² |
| Edit in Calculator |
Soverel 27 - JIBSAIL
| Luff | * 29.12 ft - (8876 mm) |
|---|---|
| Foot | * 13.02 ft - (3968 mm) |
| Leech | * 25.73 ft - (7843 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 11.5 ft - (3505 mm) |
| Deck Angle | * 12.01 ° |
| Area | * 167.45 ft² |
| Edit in Calculator |
Soverel 27 - GENOA
| Luff | * 34.58 ft - (10540 mm) |
|---|---|
| Foot | * 15.96 ft - (4865 mm) |
| Leech | * 32.76 ft - (9985 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 15 ft - (4572 mm) |
| Deck Angle | * 4.04 ° |
| Area | * 259.33 ft² |
| Edit in Calculator |
Soverel 27 - ASYMMETRICAL
| Luff | 39 ft - (11887 mm) |
|---|---|
| Foot | 18 ft - (5486 mm) |
| Leech | 36 ft - (10973 mm) |
| Perc LP | * 165 % |
| Area | * 526 ft² |
| Edit in Calculator |
Soverel 27 - SPINNAKER
| Stays | 37.33 ft - (11378 mm) |
|---|---|
| MidGirth | * 18 ft - (5486 mm) |
| Foot | * 18 ft - (5486 mm) |
| Perc LP | * 180 % |
| Area | * 571 ft² |
| Edit in Calculator |
Soverel 27 - SPINNAKER
| Stays | * 34.58 ft - (10540 mm) |
|---|---|
| MidGirth | * 18 ft - (5486 mm) |
| Foot | * 18 ft - (5486 mm) |
| Perc LP | * 180 % |
| Area | * 529 ft² |
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
