Tammie Norrie
Description
The Tammie Norrie, designed by Iain Oughtred in 1993, is a 14 ft 6 in (4.42 m) glued-lapstrake plywood sailing canoe inspired by traditional Shetland skiffs, optimized for solo or light-crew coastal exploration, fishing, and camp-cruising in sheltered waters with a shallow-draft hull, wineglass sections, and built-in flotation. Featuring a 68 ft² (6.3 m²) dipping lug sail on an unstayed mast (requiring the classic yard dip to tack), a daggerboard, and efficient rowing with 7–8 ft oars, it weighs around 140–160 lbs. (64–73 kg), offers sitting headroom under a sliding hatch, and sleeps one under a boom tent. Built from 4–6 mm marine ply using stitch-and-glue lapstrake, the Tammie Norrie excels in light-air performance, stability, and portability, with detailed plans available from the WoodenBoat Store or Classic Marine, earning praise for its graceful lines, forgiving handling, and authentic traditional rig among amateur builders and heritage sailors.
Construction Details
| Designer | Iain Oughtred |
|---|---|
| Length | 13.500 ft |
| LOA | 13.500 ft |
| LWL | 11.000 ft |
| Beam | 4.500 ft |
| Displacement | 170 lb |
| Max Draft | 3.500 ft |
| Min Draft | 0.830 ft |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | - |
| e | - |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| - | - | - | - | - | - | - | - |
Sails
Tammie Norrie - 4-SIDED SAIL
| Luff | 7.05 ft - (2149 mm) |
|---|---|
| Foot | 9.51 ft - (2899 mm) |
| Leech | 14.5 ft - (4420 mm) |
| Head | 8.76 ft - (2670 mm) |
| Diagonal | 11.49 ft - (3502 mm) |
| Tack Angle | 86.53 ° |
| Area | 83.79 ft² |
| Comments | 4-sided 4-SIDED SAIL sail |
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
