Farrier Trailer Tri 720
Description
The TrailerTri 720 (also known as the Farrier TrailerTri 720 or TT720) is a 23.62–24.0-foot (LOA approx. 24 ft / 7.32 m) trailerable folding trimaran designed by New Zealand naval architect Ian Farrier in 1976. It was sold primarily as plans for amateur/owner-builders using plywood/epoxy construction, with the first boats appearing in the late 1970s–early 1980s. No factory production run existed; hundreds of hulls were built worldwide by home builders over the decades, making it one of the earlier and most successful designs in Farrier’s folding-trimaran lineage (preceding the famous F-27). The boat pioneered many features that later defined Farrier’s F-boats, including a folding beam system for easy trailering and storage, narrow main hull with rockered U-shaped sections, and high-clearance amas (outriggers).
Construction Details
| Designer | Ian Farrier |
|---|---|
| Builder | Home Built |
| Length | 23.620 ft |
| LOA | 23.620 ft |
| LWL | 17.030 ft |
| Beam | 14.010 ft |
| Displacement | 1698 lb |
| Max Draft | 3.740 ft |
| Min Draft | 1.180 ft |
| Year Built | 1976 |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | 28.58 ft |
| e | 9.67 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| - | - | 28.58 ft | 9.67 ft | - | - | - | - |
Blueprints
Sails
Farrier Trailer Tri 720 - MAINSAIL
| Luff | 28.58 ft - (8711 mm) |
|---|---|
| Foot | 9.67 ft - (2947 mm) |
| Leech | * 29.64 ft - (9034 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 29.85 ft - (9098 mm) |
| Head (inches) | * 4.5 in - (114 mm) |
| Area | * 142.72 ft² |
| Edit in Calculator |
Farrier Trailer Tri 720 - JIBSAIL
| Luff | 25.918 ft - (7900 mm) |
|---|---|
| Foot | 9.186 ft - (2800 mm) |
| Leech | 22.309 ft - (6800 mm) |
| Length Perpendicular | * 7.72 ft - (2353 mm) |
| Area | * 99.98 ft² |
| Edit in Calculator |
Farrier Trailer Tri 720 - JIBSAIL
| Luff | 28.5 ft - (8687 mm) |
|---|---|
| Foot | 10.17 ft - (3100 mm) |
| Leech | 24.58 ft - (7492 mm) |
| Length Perpendicular | 8.58 ft - (2615 mm) |
| Area | * 122.22 ft² |
| Edit in Calculator |
Farrier Trailer Tri 720 - GENOA
| Luff | 31.25 ft - (9525 mm) |
|---|---|
| Foot | 15.5 ft - (4724 mm) |
| Leech | 28.75 ft - (8763 mm) |
| Length Perpendicular | * 14.19 ft - (4325 mm) |
| Area | * 221.67 ft² |
| Edit in Calculator |
Farrier Trailer Tri 720 - GENOA
| Luff | 28.5 ft - (8687 mm) |
|---|---|
| Foot | 13.17 ft - (4014 mm) |
| Leech | 25.25 ft - (7696 mm) |
| Length Perpendicular | 11.67 ft - (3557 mm) |
| Area | * 166.27 ft² |
| Edit in Calculator |
Farrier Trailer Tri 720 - ASYMMETRICAL
| Luff | 30 ft - (9144 mm) |
|---|---|
| Foot | 16 ft - (4877 mm) |
| Leech | 27.5 ft - (8382 mm) |
| Area | * 360 ft² |
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
