Tripp 47
Description
The Tripp 47 is a high-performance racer/cruiser sailboat designed by William H. "Bill" Tripp III and built primarily by Carroll Marine (with at least one example by Concordia Yachts) in the early-to-mid 1990s. It was conceived as an offshore-capable "thoroughbred" with a strong racing pedigree (including successes in events like the Chicago Mac, Sydney Hobart, and other classics) while offering surprising interior volume and comfort for its performance focus.
Construction Details
| Designer | William H. Tripp III |
|---|---|
| Builder | Carroll Marine |
| Length | 47.000 ft |
| LOA | 47.000 ft |
| LWL | 38.670 ft |
| Beam | 13.670 ft |
| Displacement | 18800 lb |
| Ballast | 9500 lb |
| Max Draft | 9.000 ft |
| Year Built | 1993 |
The standard boat dimensions
| i | 56.25 ft |
|---|---|
| j | 16.33 ft |
| p | 61.50 ft |
| e | 22.75 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 56.25 ft | 16.33 ft | 61.50 ft | 22.75 ft | - | - | - | - |
Sails
Tripp 47 - MAINSAIL
| Luff | * 61.5 ft - (18745 mm) |
|---|---|
| Foot | * 22.75 ft - (6934 mm) |
| Leech | * 64.65 ft - (19705 mm) |
| Tack Angle | * 87.99 ° |
| Diagonal | * 64.82 ft - (19757 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | 698.92 ft² |
| Edit in Calculator |
Tripp 47 - JIBSAIL
| Luff | * 46.86 ft - (14283 mm) |
|---|---|
| Foot | * 21.31 ft - (6495 mm) |
| Leech | * 41.31 ft - (12591 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 18.78 ft - (5724 mm) |
| Deck Angle | * 12 ° |
| Area | 440.07 ft² |
| Edit in Calculator |
Tripp 47 - GENOA
| Luff | * 55.64 ft - (16959 mm) |
|---|---|
| Foot | * 26.1 ft - (7955 mm) |
| Leech | * 52.67 ft - (16054 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 24.5 ft - (7468 mm) |
| Deck Angle | * 4 ° |
| Area | 681.44 ft² |
| Edit in Calculator |
Tripp 47 - SPINNAKER
| Stays | * 55.64 ft - (16959 mm) |
|---|---|
| MidGirth | * 29.39 ft - (8958 mm) |
| Foot | * 29.39 ft - (8958 mm) |
| Perc LP | * 180 % |
| Area | 1389.97 ft² |
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
