Victoire 22
Description
The Victoire 22 is a classic Dutch pocket cruiser designed in the early 1960s by Dick Koopmans (of D. Koopmans Jachtontwerpers) and built by Victoire Yachts (also known as Victoire Jachtbouw) in the Netherlands. Production ran from 1961 onward, with approximately 1,100 hulls built over the years, making it one of the more successful small Dutch production sailboats of its era. It was aimed at serious coastal and inland cruising (including North Sea conditions) with a focus on robust construction, stability, and simplicity rather than high performance.
Construction Details
| Designer | Dick Koopmans |
|---|---|
| Builder | Victoire Yachts (Netherlands) |
| Length | 21.650 ft |
| LOA | 21.650 ft |
| LWL | 18.700 ft |
| Beam | 7.220 ft |
| Displacement | 2535 lb |
| Ballast | 992 lb |
| Max Draft | 3.120 ft |
| Year Built | 1961 |
The standard boat dimensions
| i | 22.75 ft |
|---|---|
| j | 7.87 ft |
| p | 20.67 ft |
| e | 9.84 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 22.75 ft | 7.87 ft | 20.67 ft | 9.84 ft | - | - | - | - |
Blueprints
Sails
Victoire 22 - MAINSAIL
| Luff | * 20.67 ft - (6300 mm) |
|---|---|
| Foot | * 9.84 ft - (2999 mm) |
| Leech | * 22.42 ft - (6834 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 22.58 ft - (6882 mm) |
| Head (inches) | * 4.5 in - (114 mm) |
| Area | 101.56 ft² |
| Edit in Calculator |
Victoire 22 - JIBSAIL
| Luff | * 19.26 ft - (5870 mm) |
|---|---|
| Foot | * 10.57 ft - (3222 mm) |
| Leech | * 16.51 ft - (5032 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 9.05 ft - (2758 mm) |
| Deck Angle | * 12 ° |
| Area | 87.19 ft² |
| Edit in Calculator |
Victoire 22 - GENOA
| Luff | * 22.87 ft - (6971 mm) |
|---|---|
| Foot | * 12.83 ft - (3911 mm) |
| Leech | * 21.39 ft - (6520 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 11.81 ft - (3600 mm) |
| Deck Angle | * 4 ° |
| Area | 134.96 ft² |
| Edit in Calculator |
Victoire 22 - SPINNAKER
| Stays | * 22.87 ft - (6971 mm) |
|---|---|
| MidGirth | * 14.17 ft - (4319 mm) |
| Foot | * 14.17 ft - (4319 mm) |
| Perc LP | * 180 % |
| Area | 275.46 ft² |
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
