Westsail 42
Description
The Westsail 42 is a heavy-displacement American fiberglass bluewater cruising cutter (with ketch and occasional yawl variants also offered) designed by William I.B. "Bill" Crealock as his ideal no-compromise passagemaker for a cruising couple, drawing on traditional double-ender influences while using modern fiberglass construction. It was built by Westsail Corporation (USA) in Costa Mesa, California, with hulls 1–116 laminated between 1974 and early 1980; the molds were later sold to Jomarco, which completed hulls 117–119, for a total of 119 boats produced. The design features ultra-thick hand-laid solid fiberglass construction (often described as "overbuilt" with core samples inches thick), a long keel with attached rudder for excellent tracking and self-steering, encapsulated lead ballast, a center-cockpit layout (the related Westsail 43 used the same hull with an aft cockpit), and a spacious, liveaboard-friendly interior with high headroom, full galley, navigation station, and private cabins.
Construction Details
| Designer | WIB Crealock |
|---|---|
| Builder | Westsail Corporation (USA) |
| Length | 42.920 ft |
| LOA | 42.920 ft |
| LWL | 33.330 ft |
| Beam | 13.000 ft |
| Displacement | 31500 lb |
| Ballast | 12000 lb |
| Max Draft | 5.800 ft |
| Year Built | 1974 |
The standard boat dimensions
| i | 49.50 ft |
|---|---|
| j | 21.24 ft |
| p | 44.53 ft |
| e | 17.13 ft |
| p2 | 34 ft |
| e2 | 14 ft |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 49.50 ft | 21.24 ft | 44.53 ft | 17.13 ft | 34 ft | 14 ft | - | - |
Documents
Sails
Westsail 42 - MAINSAIL
| Luff | * 44.53 ft - (13573 mm) |
|---|---|
| Foot | * 17.13 ft - (5221 mm) |
| Leech | * 46.87 ft - (14286 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 47.15 ft - (14371 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | * 390.91 ft² |
| Edit in Calculator |
Westsail 42 - JIBSAIL
| Luff | * 43.09 ft - (13134 mm) |
|---|---|
| Foot | * 29.91 ft - (9117 mm) |
| Leech | * 35.56 ft - (10839 mm) |
| Percentage LP | * 115.02 % |
| Length Perpendicular | * 24.43 ft - (7446 mm) |
| Deck Angle | * 12 ° |
| Area | * 526.4 ft² |
| Edit in Calculator |
Westsail 42 - JIBSAIL
| Luff | 49.5 ft - (15088 mm) |
|---|---|
| Foot | 26.5 ft - (8077 mm) |
| Leech | 44 ft - (13411 mm) |
| Percentage LP | * 110.55 % |
| Length Perpendicular | * 23.48 ft - (7157 mm) |
| Deck Angle | * 4.4 ° |
| Area | * 581.1 ft² |
| Edit in Calculator |
Westsail 42 - GENOA
| Luff | * 51.17 ft - (15597 mm) |
|---|---|
| Foot | * 35.83 ft - (10921 mm) |
| Leech | * 47.16 ft - (14374 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 31.86 ft - (9711 mm) |
| Deck Angle | * 4.01 ° |
| Area | * 815.08 ft² |
| Edit in Calculator |
Westsail 42 - ASYMMETRICAL
| Luff | 51.75 ft - (15773 mm) |
|---|---|
| Foot | 32 ft - (9754 mm) |
| Leech | 48.75 ft - (14859 mm) |
| Perc LP | * 165 % |
| Area | * 1242 ft² |
| Edit in Calculator |
Westsail 42 - YANKEE
| Luff | 47.5 ft - (14478 mm) |
|---|---|
| Foot | 26.25 ft - (8001 mm) |
| Leech | 33.5 ft - (10211 mm) |
| Percentage LP | * 84.32 % |
| Length Perpendicular | * 17.91 ft - (5459 mm) |
| Deck Angle | * 23.75 ° |
| Area | * 425.38 ft² |
| Edit in Calculator |
Westsail 42 - STAYSAIL
| Luff | 32.92 ft - (10034 mm) |
|---|---|
| Foot | 12.75 ft - (3886 mm) |
| Leech | 27.92 ft - (8510 mm) |
| Percentage LP | 85 % |
| Length Perpendicular | * 10.6 ft - (3231 mm) |
| Deck Angle | * 11.4 ° |
| Area | * 174.43 ft² |
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
