Whitby 27 (Elvstrom 1/4 Ton)
Description
The Whitby 27 (also known as the Whitby 27 1/4 Ton or occasionally referred to as the Elvstrom 1/4 Ton or Bianca 27 in some contexts) is a Canadian fiberglass fin-keel (with skeg-hung rudder) masthead sloop designed by the Danish naval architecture firm Elvstrøm & Kjærulff. It was built by Whitby Boat Works Ltd. in Ajax, Ontario, as a compact, nimble 1/4-ton racer/cruiser with a focus on good light-air performance, responsive handling, and weekend/coastal sailing capability. Introduced in 1976, it featured solid GRP construction, a relatively light displacement for the era, and a practical but basic interior layout suited to 4 people. Production was very short-lived, running only from 1976 to 1977, during which just 16 boats were completed—making it one of the rarest models from Whitby Boat Works (a yard better known for its larger Alberg and Whitby 42 designs).
Construction Details
| Designer | Elvstrom and Kjaerluff |
|---|---|
| Builder | Whitby Boat Works Ltd. (Canada) |
| Length | 27.000 ft |
| LOA | 27.000 ft |
| LWL | 20.000 ft |
| Beam | 8.500 ft |
| Displacement | 3740 lb |
| Ballast | 1500 lb |
| Max Draft | 4.890 ft |
| Year Built | 1976 |
The standard boat dimensions
| i | 31.16 ft |
|---|---|
| j | 9.84 ft |
| p | 27.55 ft |
| e | 8.69 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 31.16 ft | 9.84 ft | 27.55 ft | 8.69 ft | - | - | - | - |
Sails
Whitby 27 (Elvstrom 1/4 Ton) - MAINSAIL
| Luff | * 27.55 ft - (8397 mm) |
|---|---|
| Foot | * 8.69 ft - (2649 mm) |
| Leech | * 28.5 ft - (8687 mm) |
| Tack Angle | * 88.02 ° |
| Diagonal | * 28.6 ft - (8717 mm) |
| Head (inches) | * 4 in - (102 mm) |
| Area | 119.58 ft² |
| Edit in Calculator |
Whitby 27 (Elvstrom 1/4 Ton) - JIBSAIL
| Luff | * 26.14 ft - (7967 mm) |
|---|---|
| Foot | * 13 ft - (3962 mm) |
| Leech | * 22.75 ft - (6934 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 11.32 ft - (3450 mm) |
| Deck Angle | * 12 ° |
| Area | 147.87 ft² |
| Edit in Calculator |
Whitby 27 (Elvstrom 1/4 Ton) - GENOA
| Luff | * 31.04 ft - (9461 mm) |
|---|---|
| Foot | * 15.87 ft - (4837 mm) |
| Leech | * 29.22 ft - (8906 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 14.76 ft - (4499 mm) |
| Deck Angle | * 4 ° |
| Area | 229.12 ft² |
| Edit in Calculator |
Whitby 27 (Elvstrom 1/4 Ton) - SPINNAKER
| Stays | * 31.04 ft - (9461 mm) |
|---|---|
| MidGirth | * 17.71 ft - (5398 mm) |
| Foot | * 17.71 ft - (5398 mm) |
| Perc LP | * 180 % |
| Area | 467.26 ft² |
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
