Wineglass Wherry 14
Description
The Wineglass Wherry 14 is a lightweight, elegant 14-foot plywood pulling boat (rowing skiff) designed by John Lockwood, founder of Pygmy Boats (Port Townsend, Washington). Introduced in 1990, it draws inspiration from traditional New England beach-launched working craft, blending features of Maine salmon wherries (Penobscot Bay) and New Jersey Seabright skiffs. It uses modern stitch-and-glue construction with wood-core, glass, and epoxy for a rugged yet extremely light hull. Over 1,000 hulls have been built (many from kits or plans), making it one of the more successful small traditional-style rowing boats of its era. Designer John Lockwood built his own example and used it for a month-long, 206-mile family camp-cruising expedition in 1995. The boat excels as a fast, stable rowing skiff for exercise, exploring, or light camp-cruising, with excellent tracking and a wineglass transom for buoyancy and clean water flow astern. It is primarily a rowing boat (not a dedicated sailboat), though some owners have added simple sailing rigs (leg-o’-mutton or sprit) for occasional use.
Construction Details
| Designer | John Lockwood |
|---|---|
| Builder | Home Built |
| Length | 14.000 ft |
| LOA | 14.000 ft |
| Beam | 4.000 ft |
| Displacement | 90 lb |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | 13 ft |
| e | 6.60 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| - | - | 13 ft | 6.60 ft | - | - | - | - |
Documents
Sails
Wineglass Wherry 14 - LEG-O-MUTTON
| Luff | 13 ft - (3962 mm) |
|---|---|
| Foot | 6.6 ft - (2012 mm) |
| Leech | * 13.83 ft - (4215 mm) |
| Tack Angle | * 84.46 ° |
| Diag (clew/head) | 14 ft - (4267 mm) |
| Head (Inches) | * 3.5 |
| Area | * 44.35 ft² |
| Edit in Calculator |
Wineglass Wherry 14 - SPRIT
| Luff | 7.65 ft - (2332 mm) |
|---|---|
| Foot | 7.65 ft - (2332 mm) |
| Leech | 10.53 ft - (3210 mm) |
| Tack Angle | * 88.44 ° |
| Diag (clew/throat) | 10.67 ft - (3252 mm) |
| Head | 5.3 ft - (1615 mm) |
| Area | * 56.44 ft² |
| Edit in Calculator |
Wineglass Wherry 14 - STANDING LUGSAIL
| Luff | 5.67 ft - (1728 mm) |
|---|---|
| Foot | 8.167 ft - (2489 mm) |
| Leech | 11.42 ft - (3481 mm) |
| Tack Angle | * 81.75 ° |
| Diag (clew/throat) | 9.25 ft - (2819 mm) |
| Head | 9.167 ft - (2794 mm) |
| Area | * 64.16 ft² |
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
